HDMI Cable

HDMI Cable
  • Ideal for High Definition Multimedia Interface Applications
  • Ultra Flexible Cable for Confined Area and Continuous Motion
  • Meets HDMI 1.3 Digital Audio/Video Specifications

Comprised of 4 individually dual shielded 100 ohm and one bundle of 5 twisted 28 AWG pairs with an overall shield, Cicoil's Flexx-Sil™ jacketed HDMI cables are designed for highly demanding high resolution video signal transmission applications. Cicoil's design is an excellent alternative to standard HDMI cables where resistance to mechanical stress, temperature extremes, vibration, tight bending and harsh environments is required.

Applications High Definition Multimedia Interfaces

HDMI Cable
  • Bulk Cable

    • Amp Rating: 5
    • Conductor Gauge: 28 AWG
    • No. of Paired Conductors: 9
    • A - Width (inches): 0.77
    • B - Height (inches): 0.21
    HDMI-2000
    Part Numbers Price per foot
    HDMI-2000 LOGIN Order Now

    Complete Assemblies

    Signal (J1): HDMI HDMI-2000
    Cable Length (ft) Part Numbers Price
    3 HDMI-2000-CA003 LOGIN Order Now
    6 HDMI-2000-CA006 LOGIN Order Now
    12 HDMI-2000-CA012 LOGIN Order Now

    Other connector types available. Please contact Cicoil.

    E-mail or Speak to an Engineer: 661-670-2809

    Click BUY NOW to purchase from Digi-Key Prices shown are Cicoil list prices. DigiKey prices may vary.

  • Mechanical

    • Conductors: Ultra flexible, finely stranded, tinned copper
    • Shielding: Ultra flexible, braided shields, with 90% nominal coverage
    • Minimum Bend Radius:
    • - 6x cable height for intermediate flex
    • - 10x cable height for continuous flex
    • Flex Life: 10,000,000 cycles nominal
    • Outer Jacket Durometer Rating: 65 (Shore A)

    Environmental

    • Temperature Rating: -65°C to +165°C
    • Moisture Rating: Submersible, Salt Water Resistant
    • Clean Room Rating: Class 1, Zero Particulates
    • Extreme Environments: Sunlight, UV Light, Alcohol, Chemical and Oil Resistant

    Electrical

    • Outer Jacket Dielectric Strength: 450 volts/mil (17.7 kv/mm)
